INDIVIDUAL TEST JIGS

Whether individual components, assemblies, or complete products – we establish the connection

Custom-tailored to your test specimen

Contacting of connector pins or other contacts across multiple axes

Any interface such as D-sub connector, USB, RJ45, etc.

Optional integration of limit switches, switches, indicators, fans, sensors, QR scanners, etc.

Heavily stressed areas can be designed as replaceable wear parts

Examples

Small adapter, large box

A large housing for the measurement technology was required here. On it are two simple receptacles for test objects, which are each contacted from two directions.

XXL-Test fixture

This is a hybrid solution made of aluminum strut profiles and additively manufactured components for contacting a 1.2 meter long test object. A rotating shaft is coupled to the lateral linear guides via belts and ensures that the mechanism runs smoothly without jamming.

Hand-held test fixtures

A hand-held test fixture for low-wear contacting of a vehicle connector.

Test jig for plugs

Another hand-held test jig for low-wear contacting of a vehicle connector.

Contacting by own weight

A test jig for power steering systems that contact the test contact pins by their own weight. An inductive proximity sensor and LED display elements are also integrated.

Contacting in multiple axes

With this, a test object installed in a housing can be contacted from several directions. When the hood is closed, the slides automatically move into the test object. At the same time, the hood is locked electrically and contact protection is provided.

Temperature resistance

A test jig for use in a climate chamber at extreme temperatures. With up to 7 drawers, up to 35 test items can be inserted and electrically contacted using a lever.

Connector panels

A large adapter with touch protection and extensive connector panel on the back.

Test jig for stranded wires

A simple test jig for uncomplicated contacting of stripped strands in series production.
